Inverter condensing unit Area iCOOL MAX 17D MHP
Inverter condensing unit Area iCOOL MAX 17D MHP - Afbeelding 2
Inverter condensing unit Area iCOOL MAX 21D MHP
Inverter condensing unit Area iCOOL MAX 21D MHP Login om prijzen te bekijken
Back to products
Inverter condensing unit Area iCOOL MAX 17D MHP
Inverter condensing unit Area iCOOL MAX 17D MHP Login om prijzen te bekijken

Inverter condensing unit Area iCOOL MAX 17D MHP

Login om prijzen te bekijken

Compare
Add to wishlist
Artikelnummer: Area-iCOOL - MAX 17D MHP inverter Categorie: Tags: , ,
Beschrijving

Aanvullende informatie
Power supply380/415 V-50 Hz-3 ph
Capacitycapacity at -30/32°C R449a = 17.20 kW
Weight320 kg
width745 mm
length1327 mm
height1677 mm
Suction connection28 mm
Liquid connection16 mm
Suitable compressor modelC-SBS180H00B/ C-SBN303H38G
Type of oilFV68S
Air flow9500 m3/h
MCC16/11.1 A
Receiver volume15 dm3
Number x Diameter of fan1 x 560 mm
RefrigerantR404A, R448A, R449A,
CertificatesCE, REACH, RoHS, TUV
TechnologyInverter
